Product details
Low-noise thermal printing,Easy paper-roll installation, Easy paper jam Clearance,Easy maintenance for tasks such as head cleaning.Command protocol is based on ESC / POS standard , Various Layouts are possible by using page modeCharacters can be scaled up to 64times as large as standard size. Repeated operation and copy ptinting are possible.Character front size (12*24/9*17/24*24 font) optional. Built-in interface provides control capability for cash drawer
Specifications
KEY FEATURES
- Features and Specifications
- Function TEP – 220MC
- Print method Thermal line printing
- Print speed 220 mm / sec
- Paper width 79.5 ±0.5 mm
- Print columns 576 dots / line
- Dot density 203 dpi (8 dots / mm)
- Print character ANK Character
- Font A: 12*24 dots; Font B: 9*17 dots
- Simplify / Traditional: 24*24dots
- Language English / French / German / Denish / Spanish / Japanese / Korean
- Interface Parallel / USB
- Cutter Full or Partial Cut
- Reliability print 100Km
- Power supply DC 24V
- Cash Drawer DC 12-24V/1A
- Kitchen Print Support
- Temperature 0 ~ 50 ° C
- Paper thickness 0.06 ~ 0.08 mm
- Dampness 10 ~ 80 %
- Barcode mode UPC-A / UC-E / JAN13 (EAN13) / JAN8 (EAN8 / CODE39 / ITF / CODABAR / CODE93 / CODE128
- Drivers Win9x / WinME / Win2000 / WinNT / WinXP
- Compatible with EPSON, SAMSUNG
- Print command Compatible with ESC/POS
- External dimension 145 * 203 * 135 mm (W*D*H)
- Adaptor Power Input AC 110V / 220V, 50~60Hz
- Adaptor Power Output DC24V / 2.5A
- Printer Power Input DC24V / 2.5A
- Cash Darwer DC24V / 2.5A
- Work Temperature 0~45°C, Dampness:10~80%
- Storage Temperature -10~50°C, Dampness:10~90%
WHAT’S IN THE BOX
24 volts adapter.USB connector cable.drivers and user manual
SPECIFICATIONS
- SKU: EP266EL0YICGANAFAMZ
- Care Label: nil
- Main Material: pvc
- Size (L x W x H cm): 14.5 *13.5 * 20.3
- Weight (kg): 2
This product has not been rated yet
